One person removes a wall painting sample while another assists inside the Tomb of Tutankhamen

Tiny samples of the wall paintings, coffin and sarcophagus were taken for analysis by the GCI and Laboratory of Applied Microbiology, School of Engineering and Applied Sciences, Harvard University

Scientific investigation is critical to understanding specific issues in Tutankhamen's tomb. Analysis of wall painting materials and technology was undertaken, including identification of pigments, binding medium, plaster layers, and previous treatment materials, such as adhesives. Other areas of investigation included study of environmental conditions, geotechnical and hydrological research and microbiological analysis to determine whether the brown spots found on the surface of the paintings pose a continuing risk.

Scientific Methods

Methods included:

In-situ instrumental analysis: Non-contact, non-invasive examination techniques such as technical imaging, portable X-ray diffraction (XRD), portable X-ray fluorescence (XRF), and work with a handheld microscope to study the wall paintings, sarcophagus, and outermost coffin.

Ex-situ instrumental analysis of samples: A limited number of samples were approved by the Egyptian Supreme Council of Antiquities for analysis at the Conservation Institute. Therefore, sampling areas were selected carefully, building upon information from in-situ visual examination and noninvasive study of the paintings. The main focus of the sampling was to look more in depth at causes of deterioration in order to develop the conservation plan. Analysis was undertaken at the Institute using cross-sections, Raman microspectroscopy, X-ray diffraction (XRD), gas chromatography with mass spectrometry (GC/MS), pyrolysis-gas chromatography/mass spectrometry (Py-GC/MS), Fourier-transform infrared microspectroscopy (FTIR), environmental scanning electron microscopy with energy dispersive X-ray spectroscopy (ESEM-EDX), and enzyme-linked immunosorbent assay (ELISA).

Microbiological investigation: Already present on the paintings when Carter entered the burial chamber in 1923, the brown spots have been the subject of numerous investigations and treatment interventions. However, no proof has ever been presented that they are biologically active. Investigation of the brown spots was therefore an important component of the project and in particular determining whether they pose a continuing risk to the paintings. Methods utilized include photographic monitoring, culturing of swabs, DNA analysis using polymerase chain reaction (PCR), chemical analysis, and microscopy. The preliminary findings have for the first time confirmed that the spots, microbiological in origin, are no longer viable.

Environmental monitoring: Environmental monitoring was undertaken to assess the effects of exterior conditions and visitation on the microclimate within the tomb. Parameters monitored in the tomb include relative humidity, temperature, particulate matter, carbon dioxide, and rates of air exchange.

Geotechnical investigation of the stability of KV 62.

Hydrological study of flood risks to the tomb and methods of prevention.

Literature research: For all investigations, background research was conducted in order to place the project findings within the wider context of existing knowledge in these areas of study. A report on the scientific investigation of the tomb wall paintings was completed in 2012, contributing to the development of a detailed conservation proposal during the second phase of the project.

A person installs temperature and relative humidity probes inside the Tomb of Tutankhamen

GCI scientist installing temperature and relative humidity probes in the burial chamber
